DialNexa Integration Functions

Understand DialNexa integration functions for Wati, Resend, workflow actions, agent actions, invocation payloads, missing fields, provider messages, errors, and latency.

DialNexa integration functions are catalog actions that can run from workflows or eligible agent tools. Each execution stores provider, adapter, action, source context, redacted payloads, missing fields, provider message id, error details, and latency.

Integration invocation data is where vague action failures become specific enough to fix.

Function Types Users Will See

Provider	Function type	Typical inputs	Typical result
Wati	Send WhatsApp session or template message.	Phone number, message body, template name, parameters, broadcast name.	Message accepted or provider error with details.
Resend	Send email.	From email, to email, subject, text body.	Email accepted or provider error with details.

Invocation Evidence

Field	Meaning
source_type	Where the action came from, such as workflow or agent context.
source_ref_id	Id of the source that triggered the action.
workflow_id and workflow_lead_id	Workflow context for Application node actions.
agent_id and agent_version_number	Agent context when the action is tied to a caller.
call_log_id	Call context when available.
request_payload_redacted	Input sent to the provider with sensitive values removed.
response_payload_redacted	Provider response with sensitive values removed.
missing_fields	Required fields that were not available.
provider_message_id	Provider-side message id when returned.
error_code and error_message	Provider or adapter failure details.
latency_ms	How long the action took.

Use Invocation Data To Decide The Fix

Missing fields

Fix variable mapping, call attribute extraction, or static config.

Credential failure

Reconnect or validate the provider connection.

Provider error

Check provider rules, template approval, sender identity, or rate limits.

High latency

Move the action later in the flow, add failure handling, or avoid blocking live speech.

Function Design Rules

1. Name the business action

   Use the action that matches the desired outcome, not the closest-looking logo.

2. Map every required input

   Required fields should come from lead variables, call attributes, dynamic variables, or static configuration.

3. Plan the failure path

   Provider errors, missing fields, and rate limits should have a clear workflow path.

4. Review one invocation

   Before scaling, inspect the redacted request, response, latency, and message id.

Integration Function Questions

Why is payload redacted?

Sensitive values should not be exposed in routine debugging views. Redaction lets teams debug structure without exposing secrets.

Why did the success route not run?

Check invocation status, missing fields, provider response, and whether the node output is wired to success.

Can an agent call these actions during a live call?

Only expose an action when it has a clear caller-facing purpose and the agent function description explains exactly when to call it.

Why does latency matter?

If an action blocks a live response, slow provider latency becomes awkward caller silence. Place slow actions after the call when possible.
